Performance Parameters |
RFID Protocol: | EPC Class1 Gen2, ISO18000-6C |
Frequency: | (US) 902-928MHz, (EU) 865-868MHz |
Chip: | NXP UCODE 8 |
Storage: | EPC 128bits , User 32bits, TID 96bits |
Rewrite times: | 100000 |
Func: | Read/Write |
Data preservation: | 50 years |
Reading distance(handheld reader): | 1-1.5M,mounted on metal surface(The reading distance varies according to different readers) |
Application: | Intelligent warehouse management, pallet management, industrial manufacturing. |
Physical Parameters |
Size: | L:40mm*W:25.9*T:6.5mm |
Material: | Stainless steel,potting |
Color: | Gold/Natural Color |
Install method: | Locking screws, adhesive, riveting |
Weight: | 14.2g |
Environmental Parameters |
IP Level: | IP68 |
Storage temperature: | -20℃ - +80℃ |
Working temperature: | -20℃-+180℃ |
Material properties | High and low temperature resistance, wear resistance, anti aging, can withstand high weight impact |
Tolerable gravity | 3 tons of collision avoidance |
